End of programme when ...
... $ Start/Reload flashes and -0- appears on the display
panel.
Interrupting the programme
Programmes at high temperatures:
– Cool washing: Select / Spin.2Rinse
– Press Reload.$Start/
Programmes at lower temperatures:
– Select Rinse (deactivate 2/ Spin 2 Extra Rinse
button) or .> Drain
– Press $ Start/Reload.
Changing the programme, if ...
... you have selected the wrong programme by mistake:
– Reselect the programme.
– Press $ Start/Reload. The new programme starts from
the beginning.
Reloading laundry, if ... –> page 5
... Start/ selected and then is lit in the $Reload YES
display panel. If is lit, the washing machine door NO
cannot be opened.
– Press Reload.$ Start/
Correct installation according to the
separate Installation instructions.
Checking the machine
– Never use a damaged machine.
– Inform customer service.
Connecting the mains plug
Make sure your hands are dry.
Take hold of the plug only.
Turning the tap on
Compartment II: Detergent for the main wash,
water softener, bleach, stain remover
Sorting and loading laundry
Follow the manufacturer's care information.
According to the information on the care labels.
According to type, colour, soiling and temperature.
Do not exceed the maximum load –> .page 7
Observe the important information –> page 6.
Insert large and small items of laundry.
Close the washing machine door. Take care not to trap items of laundry
between the washing machine door and the rubber seal.
Add detergent and care products
Measure accordingly:
Amount of laundry, soiling, water hardness (ask your water supply
company) and manufacturer's instructions.
Pour liquid detergent into the appropriate dispenser and place in the drum.
Your washing machine
Congratulations ä You have opted for a modern, high-quality
domestic appliance manufactured by Bosch. The washing machine
is distinguished by its economical water and energy consumption.
Each machine that leaves our factory has been inspected thoroughly
to ensure that it functions properly and is in perfect condition.
Further information: www.bosch-home.com
Environmentally friendly waste disposal
All packaging must be disposed of in accordance with
environmental guidelines.
This appliance is certified in accordance with European Directive
2002/96/EEC on waste electrical and electronic equipment
(WEEE).
This directive provides the framework for the EU-wide collection and
reuse of used appliances.
Intended use
Contents Page
ʋIntended use .......................................................................................1
ʋProgrammes ........................................................................................1
ʋSetting and adjusting the programme ...........................................3
ʋWashing ...........................................................................................3/4
ʋAfter washing ......................................................................................4
ʋIndividual settings ..........................................................................5/6
ʋImportant information ....................................................................... 6
ʋOverview of programmes ................................................................7
ʋSafety instructions .............................................................................8
ʋConsumption values .........................................................................8
ʋCare .....................................................................................................9
ʋInformation on the display panel ....................................................9
ʋMaintenance .................................................................................... 10
ʋWhat to do if... .................................................................................. 11
Protection of the environment/Conservation tips
– Always fill the washing machine with a maximum amount of
laundry for the relevant programme.
– Wash normally soiled laundry without a pre-wash.
– Instead of , choose the programme LF Cottons 90 °C LF
Cottons 60 °C with the additional function ĈøEcoPerfect.
Comparable cleaning result with significantly lower energy
consumption.
– Measure the detergent according to the manufacturer's
instructions and water hardness.
– If the laundry is then dried in the tumble dryer, select the spin
speed according to the instructions of the dryer manufacturer.
Preparation Before washing for the first time
Wash once without any laundry –> page 9.
Setting** and adjusting programmes
Spin
speed*
Programme selector Start/
Reload
Programme selector for
switching the machine on
and off and for selecting
the programme. Can be
turned in either direction.
Programmes
Detailed overview of programmes –> .page 7
Spin speed can be selected individually, irrespective of the
selected programme and programme progress.
LF Cottons Hard-wearing fabrics
+ Prewash
Hard-wearing fabrics
,
pre-wash at 30 °C
1 Mix Different types of laundry
@ SuperQuick 15’ Short programme
2 2 Rinse/ Spin Laundry washed by hand,
Extra Rinse button activated; if only
using the spin cycle, deactivate the
button
> Drain Drain rinsing water for Rinse Hold
ÿ Wool /Hand/machine-washable wool
Delicate/Silk Delicate washable fabrics
I Easy-Care Easy-care fabrics
**If the symbol flashes in the #
display panel, the childproof lock
is active -> deactivate, .page 5
Additional functions, the options
button and spin speeds –>
Individual settings, .page 5
Select Start/Reload$
Washing
1
2
Washing
Detergent drawer with
compartments , , III~
Washing machine
door
Compartment 0u: Fabric softener, starch
Compartment I: Detergent for pre-wash
ʋfor domestic use only,
ʋfor washing machine-washable fabrics and hand-wash-
able wool in detergent solution,
ʋto be operated with cold drinking water and commer-
cially available detergents and care products which are
suitable for use in washing machines.
– Do not leave children unattended near the
washing machine.
– The washing machine is not to be used by
children or persons not familiar with the
operating instructions.
– Keep pets away from the washing machine.
Dilute viscous fabric softener and fabric conditioner with water.
This prevents blockages.
Individual settings
ʑReady in options button
When you select the programme, the relevant programme duration is displayed. You can
delay the start of the programme before it begins. The "Ready in" time can be set in
increments of one hour up to a maximum of 24 hours. Press the button Ready in
repeatedly until the required number of hours is displayed (h = hour). Choose $Start/
Reload. It is not possible to make adjustments once the programme has started.
ʑ Spin speed/ Rinse Hold
Before and while the selected programme is running, you can set the spin speed or Rinse
Hold (without final spin, laundry soaks in the last rinsing water). The effects depend on the
programme progress.
The maximum selectable spin speed depends on the model and on which programme is
currently selected.
ʑAdditional functions –> and overview of programmes, see page 7
iSpeedPerfect For washing in a shorter time with a washing outcome comparable to
that of the standard programme. Maximum load –> Overview of
programmes, page 7.
Ĉ EcoPerfect For saving energy with a washing performance comparable to that of
the standard programme.
S Easy Iron Special spin sequence with subsequent fluffing. More gentle final spin
- residual moisture in the laundry slightly increased.
2 Extra Rinse Additional rinse cycle. For areas with very soft water or for further
enhancing the spin result.
ʑChildproof lock and reloading
#
Childproof lock/
Appliance lock
You can lock the washing machine to prevent the functions you have
set from being changed inadvertently.
ON) /OFF: Press and hold the Start/Pause button for approx. 5
seconds after the start/end of the programme.
Note: The childproof lock can remain activated until you wish to start
the next programme, even after switching off the machine.
Then you can deactivate the childproof lock before the start of the
programme and activate it again as necessary once the programme
has started.
YES
Reload
If you want to add additional items of laundry after the programme has
started, choose Start/ . The machine checks whether $Reload
reloading is possible.
YES is lit: Reloading is possible.
NO YES flashes: Wait until lights up.
Note: Do not open the door until is lit.YES
NO: It is not possible to reload.
Note: For safety reasons, the washing machine door remains locked
when the water level and/or temperature is high, or during spinning.
To continue the programme, press the $ Start/Reload.
ʑ$Start/Reload
To start the programme or to subsequently load additional laundry, and to activate/deactivate
the childproof lock.
Individual settings
ʑSignal
Important information
Protecting the laundry and the machine
– Empty pockets.
– Look out for metal items (paperclips, etc.).
– Wash delicates in a laundry bag (tights, curtains, underwired bras).
– Fasten zips, do up any buttons.
– Brush sand out of pockets and collars.
– Remove curtain fittings or place in the laundry bag.
Laundry with varying degrees of soiling
Wash new items of clothing separately.
light Do not pre-wash. If required, choose the additional function i
SpeedPerfect.
Pre-treat any stains as necessary.
intense Do not load as much laundry. Choose a programme with pre-wash.
Soaking Load laundry of the same colour
Pour soaking agent/detergent into compartment in accordance with the manufacturer's II
instructions. Turn the programme selector to and press Reload. LF Cotton cold $Start/
After approx. 10 minutes, press $ Start/Reload to pause the programme. Once the required
soaking time has elapsed, press $Start/Reload again to continue the programme, or select
a different programme.
Starching Laundry must not be treated with fabric softener
Starching is possible in all wash programmes if liquid starch is used. Pour the starch in
accordance with the manufacturer's instructions into fabric softener compartment ~ (rinse first
if necessary).
Dyeing/bleaching
Dye should only be used in normal household quantities. Salt may damage stainless steel.
Always follow the dye manufacturer's instructions! Do use the washing machine for not
bleaching clothes!
2. Setting the volume
for ...
1. Activating the mode
for setting the signal
volume
Set to •1 step, the
display panel
lights up
press and hold +1 step, release
Button signals Information signals
Set to •
Setting the
volume*
Setting the
volume*
1 step
direct
* you may need to select
the function several times.
1000
800
600
Rinse Hold
All buttons are sensitive and need
only to be touched lightly. Press
and hold the options and spin
speed buttons to run through the
setting options automatically.
Additional
functions
3
Drum
Control panel
Service flap
Programme sequence displays:
ü üþüü üü# Childproof lock, washing, rinsing, spinning
1 - 24h Programme end after
Ready in
Display panel/
Options
button
Removing the washing
Open the washing machine door and remove the washing.
If (without final spin) is active: Turn the Rinse Hold
programme selector to >Drain or select the spin speed.
Select $ Start/Reload.
– Remove any foreign objects - risk of rusting.
– Leave the washing machine door and detergent
drawer open so that any residual water can
evaporate.
Turning the tap off
Not required for Aqua-Stop models –> Refer to installation
instructions.
Switching off
Turn the programme selector to .Off
(*depending on the model)
Probleemoplossing Bosch WAE 20360
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Merk: | Bosch |
| Categorie: | Wasmachine |
| Model: | WAE 20360 |
