Pagina 1/4
GB
Quick Guide
THANK YOU FOR BUYING A INDESIT PRODUCT
In order to receive a more complete assistance,
please register your product on
www.indesit.com/register
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bolts are removed.
For more detailed instructions on how to remove them, see the Installation Guide.
CONTROL PANEL
WASH CYCLE TABLE
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
DETERGENT DISPENSER DRAWER
Compartment 1: Do not pour detergent into the
compartment . 1
Detergent should only be poured into the
compartment .2
Compartment 2: Washing detergent (powder
or liquid)
Liquid detergent should only be poured in
immediately prior to the start of the wash cycle.
Compartment 3: Additives (fabric softener,
etc.)
The fabric softener should not overow the grid.
Note: If a “tablet detergent” is used, always follow the manufacturer’s
instructions.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
Maximum load 8 kg
Power input in o mode 0.5 W / in left-on mode 8 W Detergents and
Additives Recommended
detergent
Residual
dampness %
(**)
Energy
consumption
kWh
Total water lt
Laundry
temperature °C
Wash cycle Temperature Max.
spin speed
(rpm)
Max.
load for
washing
(kg)
Duration
(h : m)
Drying
Max.
load for
drying
(kg)
Wash Fabric
softener
Powder
Liquid
Setting Range 2 3
1 Mix Colours 59’ 40 °C - 40 °C 1000 8,0 * 6,0 –– – – –
2 Synthetics 59’ 30°C - 30 °C 1000 3,5 * 3,5 –– – – –
3 Cotton 45’ 40 °C - 40 °C 1200 4,5 * 4,5 –– – – –
4 Wash&Dry 90’ 30°C 30°C 1200 2,0 * 2,0 –– – – –
5 Wash&Dry 45’ 30°C 30°C 1400 1,0 * 1,0 –– – – –
6 Cotton (2) 40 °C - 60 °C 1400 8,0 3:55 6,0 49 1,400 105 45
7 Synthetics (3) 40 °C - 60 °C 1200 4,0 2:55 4,0 35 0,800 55 43
8 Wool 40 °C - 40 °C 800 2,0 * 2,0 –– – – –
9Eco 40-60 (1)
(Wash) 40 °C 40°C
1351 8,0 3:30
6,0
53 0,770 54 33
1351 4,0 2:45 53 0,650 52 36
1351 2,0 2:10 53 0,450 37 33
10 20°C 20 °C - 20 °C 1400 8,0 1:50 6,0 –49 0,160 90 22
11 White 60°C - 90 °C 1400 8,0 2:45 6,0 49 0,900 90 55
12 Cotton Dry – – – 6,0 * 6,0 – – – – – – – –
13 Synthetics Dry – – – 4,0 * 4,0 – – – – – – – –
14 Rinse – – 1400 8,0 * 6,0 – – – – – – –
15 Spin – – 1400 8,0 * 6,0 – – – – – – – –
16 Drain – – – 8,0 * – 6,0 – – – – – – – –
Required dosage Optional dosage
9Eco 40-60 (4)
(Wash & Drying) 40 °C 40 °C 1351 6.0 9:20 6.0 0 3,800 75 33
1351 3.0 5:10 3.0 0 1,980 47 32
12
3
1
7 6
4
5
32
ДДДДДДД
DISPLAY
8
1. ON/OFF button
2. TEMPERATURE button
3. OPTION buttons and indicator lights
4. START/PAUSE button and indicator light
5. DRYING button
6. SPIN button
7. WASH CYCLE SELECTOR KNOB
8. Detergent dispenser drawer
For all testing institutes:
2) Long cotton cycle: set programme 6 at temperature 40°C.
3) Long synthetics cycle: set cycle 7 at a temperature of 40°C.
* The duration of the wash cycles can be checked on the display.
** After programme end and spinning with maximum selectable spin speed, in default
programme setting.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as the
temperature and pressure of the incoming water, ambient temperature, amount of detergent,
load quantity and type, load balancing and any additional options selected.The values given
for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40-60 (Wash) - Test wash cycle in compliance with EU Ecodesign regulation
2019/2014. The most ecient programme in terms of energy and water consumption for
washing normally soiled cotton laundry.
Note: spin speed values shown on the display can slightly diers from the values stated in
the table.
Eco 40-60 (Drying)-
Test drying cycle in compliance with EU Ecodesign regulation
2019/2014
. To access “wash and dry” cycle select “Eco 40-60” wash programme and set
“Drying” option level to
“
A3
”.
The most ecient programme in terms of energy and water
consumption for washing and drying normally soiled cotton laundry. At the end of cycle the
garments can be immediately stored to the cupboard.
Probleemoplossing Indesit EWDE 861483 W UK
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Apparaatplaatsing: | Vrijstaand |
| Soort bediening: | Buttons, Rotary |
| Kleur van het product: | Wit |
| Deurscharnieren: | Links |
| Ingebouwd display: | Ja |
| Gewicht: | 65000 g |
| Breedte: | 595 mm |
| Diepte: | 535 mm |
| Hoogte: | 850 mm |
| Netbelasting: | 1850 W |
| Type stekker: | Type G |
| Aantal programma's: | 16 |
| Type lader: | Voorbelading |
| Materiaal trommel: | Roestvrijstaal |
| Snoerlengte: | 1.2 m |
| Trommelinhoud: | 58 l |
| Uitgestelde start timer: | Ja |
| Startvertraging: | 24 uur |
| Resterende tijd indicatie: | Nee |
| Kinderslot: | Nee |
| Anti-kreuk functie: | Nee |
| Gewicht verpakking: | 66450 g |
| Breedte verpakking: | 645 mm |
| Diepte verpakking: | 590 mm |
| Hoogte verpakking: | 890 mm |
| Centrifuge-droger klasse: | B |
| Geluidsniveau (wassen): | 78 dB |
| Aanpasbare centrifugesnelheid: | Ja |
| Maximale centrifugesnelheid: | 1400 RPM |
| Stroom: | 13 A |
| Beeldscherm: | LED |
| Geluidsemissieklasse: | C |
| Droogcapciteit: | 6 kg |
| Waterverbruik wassen & drogen: | 65 l |
| Water verbruik wassen: | 48 l |
| Duur cyclus (snelwas programma): | 45 min |
| Verstelbare voeten: | Ja |
| Land van herkomst: | Italië |
| Code UK-handelstarief: | 84501111 |
| Half-geladen: | Nee |
| Instelbare temperatuur: | Ja |
| Energie-efficiëntieklasse (wassen): | C |
| Energie-efficiëntieklasse (wassen en drogen): | D |
| Energieverbruik per 100 cycli (wassen): | 63 kWu |
| Energieverbruik per 100 cycli (wassen en drogen): | 307 kWu |
| Watertoevoer: | Koud |
| Verlichting in trommel: | Nee |
| Easy Iron-functie: | Ja |
| Duur wascyclus: | 210 min |
| Export Control Classification Number (ECCN): | 84501111 |
| Nominale capaciteit (wassen): | 8 kg |
| AC-ingangsspanning: | 220-240 V |
| AC-ingangsfrequentie: | 50 Hz |
| Type beeldscherm: | LED |
