Pagina 1/2

Princeton Tec

PO Box 8057, Trenton, NJ 08650

Phone: 609-298-9331

Fax: 609-298-9601

www.princetontec.com

Operating Instructions

Notice d’utilisation et d’entretien

Bedienungsanleitung

APEX

RECHARGEABLE

LED HEADLAMP

Green

above 50%

Yellow

49 - 20%

Red

below 20%

Color Battery Capacity*

ENGLISH

Configurations / Zubehör

Battery

Lithium Ion Rechargeable Battery Pack.

To charge battery pack before first use, begin by

disconnecting the pack from the light head and attaching

the USB charging lead. Next, plug this lead into a suitable

USB power source. Princeton Tec suggests a charger with

minimum output of 5V, 1A. This charger will fully charge the

battery pack in 3 to 4 hours. Faster charging will be

achieved when a charger rated for higher amperage is

used. Under normal usage, the supplied lithium ion battery

pack will last for at least 1,000 charge / discharge cycles.

General care and warnings

• Disconnect battery pack during long periods of storage.

• Properly charge the battery to maximize its lifespan.

Lithium ion batteries do not suffer from a “memory effect,”

and for battery longevity it is preferable to charge more

frequently if possible, rather than to fully deplete the

battery’s charge.

• To avoid damaging your lighting system, use only

chargers that meet the approved specifications.

• Although APEX Rechargeable is designed for use in wet

weather conditions, it is not submersible. Submerging it in

water will damage the system and void the warranty.

• To keep your lighting system looking new, use a mild

soap and water solution with a rag or sponge to periodically

wipe off dirt.

• Never submerge the light, battery pack or cables in water.

Princeton Tec cares about the environment and

recommends recycling batteries. For more information

about battery recycling, please go to:

www.batteryrecycling.com.

Battery Power Meter

Multicolored LED

With the battery pack plugged into the APEX, the BPM

(battery power meter) will indicate charge status.

*Capacity percentage is the minimum expected remaining

power needed to operate the Maxbright LED in high mode

at 0° C. The purpose of the battery power meter is to give

you a general idea of the remaining burn time. Switching

modes can create an abrupt change in battery voltage

which may cause the indicator to change color. Once the

color turns yellow, the burn time remaining depends on the

typical discharge curve for the type of batteries you are

using. After the light has been turned off, the battery voltage

might temporarily increase, causing the battery power

meter to temporarily display an artificially higher setting.

When the light is off, the battery power meter will continue

to blink for 24 hours to indicate the current status of the

batteries. After 24 hours with no activity, the battery power

meter will turn off to conserve battery power. When the light

is turned on again, it will resume functioning.

Low Battery Signaling During Use

In addition to displaying red on the battery power meter,

when there are approximately 20 minutes of run time

remaining, the Apex will blink three times in rapid

succession. You can then decide to stay at your current

light level or switch to a lower light level, which may cause

battery voltage to rise enough that the battery power meter

transitions back to yellow. When the battery power meter

returns to red, the light will blink again to alert you.

Circuitry

The Apex uses a sophisticated circuit to control the light.

Under normal circumstances, the metal heatsink will

sufficiently cool the electronics and protect the LEDs from

damage. Should the internal temperature of the light get too

hot, a backup temperature protection circuit will activate

and gradually decrease the light output until the

temperature is within the specified limits. The Apex will

automatically turn off after 12 hours of inactivity. Any button

press during the 12 hour period will reset the auto off timer.

Never attempt to disassemble the lamp housing. It is sealed

to protect the components from water and there are no

user serviceable parts inside. Disassembly will void your

warranty! To keep the heatsink at peak performance, keep

the heatsink and plastic cover free of obstructions (mud

and dirt). Do not remove the heatsink cover—it is there to

protect you from the high temperature of the heatsink

during operation. If the heatsink cover is damaged or

broken under normal use, do not use the headlamp. See

the warranty and return policy for more information.

Power Consumption

The Apex uses a current-controlled circuit that maintains

constant light output as long as the batteries have sufficient

voltage. Constant burn time is dependent on battery

condition, LEDs, and light level selected. The Ultrabright

LEDs provide the maximum level of wide-angle flood light

for task work and the Maxbright provides a tightly focused

spotlight for distance illumination.

Troubleshooting

If the Apex fails to light:

• Check the batteries for proper connection.

• Inspect the cable for damage.

If the Apex does not seem to change brightness levels:

• The battery voltage may be too low to switch to a brighter

setting. This condiditon is normal for a regulated

LED/current-controlled circuit. You are most likely to

experience this issue in the Maxbright LED mode. Recharge

your battery pack to restore performance.

• In extreme heat conditions the internal temperature of

the light may be too hot and the LED temperature

protection circuit may have activated. Allow the light to

cool and try again.

Lifetime Warranty

Due to international regulations, Princeton Tec’s lifetime

warranty can only be offered to customers in the USA.

Princeton Tec offers a 10 year warranty to our customers

outside the USA. FULL WARRANTY – Princeton Tec

warrants this product to be free from defects in

workmanship and materials under normal use for as long

as you own this product. This warranty covers all of the

component parts of the product except batteries. This

warranty does not cover deterioration due to normal wear

or damage due to misuse, alteration, negligence,

accidents, or unauthorized repair. Princeton Tec will repair

or replace parts which are defective in workmanship or

materials. Your authorized Princeton Tec Dealer and

Princeton Tec are the only facilities authorized to repair the

product. After (3) unsuccessful attempts to repair the

product, you have the right to elect replacement of the

product or a refund of the purchase price less allowance

for use of the product. NO INCIDENTAL OR CONSE-

QUENTIAL DAMAGES ARE INCLUDED IN THIS

WARRANTY. (Some states do not allow the exclusion or

limitation of incidental or consequential damages, so the

above limitations or exclusions may not apply to you.) This

warranty gives you specific legal rights, and you may also

have other rights which vary from state to state.

Princeton Tec reserves the right to change product

specifications without notice.

Return Policy

If your light fails to operate, follow these simple steps:

1) Check batteries. Recharge if necessary.

2) Contact Princeton Tec customer service at 800-257-

9080 to request an RMA number in order to send your light

for repair or replacement. No warranties will be accepted

without an RMA number.

3) If the light continues to function improperly, return it

without batteries to: Princeton Tec, 5198 Rt. 130

Bordentown, NJ 08505. Postage due and freight collect

items will not be accepted.

OFF = press & hold

(1-2 seconds)

press 1x = High

press 2x = Low

press 1x = High

press 2x = Low

press 3x = Flash

4 Ultrabright

LEDs

Maxbright

LED

Maxbright

LED

Spotlight

Ultrabright

LEDs

Wide Beam

Operation / Fonctionnement / Betrieb

Burn time is the total time that the headlamp produces a minimum of 0.25 lux at 2 meters.

0.25 lux is about the equivalent of a full moon on a clear night. Regulated burn time is

less than overall burn time.

Lithium Ion Rechargeable Battery

DISTANCE (Meters)

26 43 12067

Regulated

HIGH

Regulated

LOW

DISTANCE (Meters)

4326 12067

Regulated

20H

HIGH

Regulated

90H

LOW

Total

61H

FLASH

Headlamp

Frontale Led

Stirnlampe

Extension Cable

Câble d’extension

Verlängerungskabel

USB Charging Cable

Câble de recharge USB

USB-Ladekabel

Battery Pack

Batterie

Akku-Einheit

Helmet Mounting Strap

Sangle pour montage sur casque

Helmbefestigungsriemen

Bike Helmet Mounted

Montage sur casque de vélo

Helmbefestigung

Probleemoplossing Princeton Tec Apex Recharheable

Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp

Specificaties

Kleur van het product:	Zwart
Aantal vermogenniveau's:	3
Gewicht:	283 g
Aantal lampen:	5 lampen
Soort lamp:	LED
Vermogen lamp:	- W
Levensduur accu/batterij:	90 uur
Accu/Batterij oplaadtijd:	4 uur
Lichtstroom:	200 lm
Batterijen inbegrepen:	Ja
Batterijtechnologie:	Lithium-Ion (Li-Ion)
Type zaklamp:	Lantaarn aan hoofdband
Lichtbundelafstand (max):	120 m
