Pagina 1/8
WARNING!
• Read the instructions carefully before installing and/or using the hood.
• Before connecting, make sure that the mains voltage corresponds to the voltage on
the rating plate inside the hood. (see fig. 7)
• Once you remove the appliance from its packaging make sure it is intact. If the
product is damaged, do not use it and contact the Smeg assistance network.
• It is recommended that a qualified technician performs installation and adjustment
operations .
• The minimum distance between the cooker and the lower part of the hood must be
750mm for gas cookers and 650 mm for electric cookers.
• Before carrying out any kind of maintenance or cleaning, disconnect the hood from
the mains supply.
• Inspect and clean the filters thoroughly and in accordance with the intervals
suggested by the manufacturer.
• Do not cook or fry in a way that could result in flames being sucked into the hood and
causing a fire.
• The hood surface can be cleaned with a damp cloth and a non-bleach liquid
detergent.
• Make sure the room is properly ventilated when using the hood and other gas
appliances at the same time.
• Comply with the regulations on air discharge when operating the hood.
• The extracted air must not be routed into a duct used to discharge fumes of gas-
operated appliances.
• This appliance must not be used by children without an adult supervision
and disabled people may require assistance.
• THE MANUFACTURER CANNOT BE HELD RESPONSIBLE IF THE ABOVE
INSTRUCTIONS ARE NOT FOLLOWED.
OPERATION
This appliance has been designed to work as a
DUCTING
hood (evacuation of the
air) or RECYCLING hood (recycling of the filtered air).
• DUCTED MODE: In order to use the hood in the ducted mode, connect the motor
intake, by means of a suitable ducting hose not less than 120mm diameter, directly to
the external fumes outlet.
Note: Remove any carbon filters.
• RECIRCULATION MODE: If it is not possible to discharge fumes outside, the hood
can be used to filter and recycle the air. This way, air and fumes are filtered by the
anti-odour carbon filters and recirculated through the aerating grids on the sides of
chimney.
EN 01
Probleemoplossing Smeg KSED95P
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Crème |
| Breedte: | 900 mm |
| Diepte: | 515 mm |
| Hoogte: | 840 mm |
| Geluidsniveau: | 52 dB |
| Soort: | Muurmontage |
| Motor vermogen: | 240 W |
| Aantal motors: | 1 |
| Materiaal behuizing: | Roestvrijstaal |
| Maximale afzuigcapaciteit: | 700 m³/uur |
| Afzuigmethode: | Afvoerend/recirculerend |
| Aantal lampen: | 2 gloeilamp(en) |
| Soort vetfilter: | Metaal |
| Aantal filters: | 3 stuk(s) |
| Aantal snelheden: | 3 |
