Overview
This product is an HD video and 4K video compatible option board that
can convert in either direction between SDI signals, sent and received
from video input/output connectors (eight on NXLK-IP50Y, four on NXLK-
IP51Y) and IP video streams.
Parts Identification
NXLK-IP50Y
1 2
1 Network (LAN) connectors 1 and 2
2 SDI video connectors 1 to 8 (input/outputs)
NXLK-IP51Y
1 2
1 Network (LAN) connectors 1 and 2
2 SDI video connectors 1 to 4 (input/outputs)
Installation
To use this unit, settings must be configured according to the installation
manual. For details on acquiring the installation manual, contact your
local Sony service representative.
Status Indicator
The following states of the unit are indicated by the status indicator of
the NXL-FR316.
Indicator Status Solution
Lit green Indicates that the unit is
operating normally.
–
Blinking
orange
Indicates a warning that
has no immediate affect on
system operation.
Example:
ˎNetwork connection with
the board was interrupted.
ˎMain board and connector
board pairing is incorrect.
ˎCheck the cables
connected to the unit
and the signal status.
ˎCheck the attachment
of the board.
If the status indicator
does not change
to green after
checking these items,
contact your Sony
representative.
NXLK-IP50Y
NXLK-IP51Y
© 2020 Sony Corporation Printed in Japan
SDI-IP CONVERTER BOARD
NXLK-IP50Y
12G SDI-IP CONVERTER BOARD
NXLK-IP51Y
Operating Instructions
Probleemoplossing Sony NXLK-IP51Y
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Merk: | Sony |
| Categorie: | Niet gecategoriseerd |
| Model: | NXLK-IP51Y |
