LM 3R Laser Level57
User Manual
1. Pr uct Structure od
1 0° horizontal glass window 2 360° vertical glass window V1 36
3 0° vertical glass window V2 4 Pendulum lock 36
5 Button 6 Battery cover
7 Charging interface
8 LED indicator
2. Safety Instructions
Before using this product, please carefully read and follow the safety instructions, otherwise
the warranty may be invalid.
Warning!
Class 2 laser product
Wavelength: 635nm±10nm
L er radiation: as
Do not stare into beam
Do not directly expose to eyes
Avoid using optical instruments
3. Cautions
Some pr uct kits will provide glasses. Please note that these glasses are not safety glasses. od
They are only used to help users recognize the laser beam in strong ambient light or w n the he
light source of the laser instrument is distant.
Do not stare into beam or directly observe the laser beam via an optical instrument or set the
instrument at the eye level (to avoid damage to eyes).
Do not disassemble the laser instrument without authorization.
Do not refit the instrument without authorization in any way; otherwise it may cause
harmful laser radiation exposure.
Do not use the laser instrument around children or allow them to use it.
Exposure to Class 2 lasers for no more t n 2 seconds is generally considered safe, ha
because natural eyelid reflexes (blinking) usually can provide ade ate protection. qu
4. Operation Guidelines
When the laser instrument is locked, press and hold the V button to turn it on and emit a
horizontal laser line. At this time, the laser line will flash once every 5 seconds, and the
indicator will be green.
When the instrument is unlocked (t gle the pendulum lock to the unlocked position) and og
tur d on, it can also emit a horizontal laser line. When the instrument exceeds its ne
self-leveling range (3°±1°), the laser beam will flash quickly.
Continuously press the V button to step through the operating modes of the instrument.
Generate 1# vertical plane
G erate 2# vertical plane en
Simultan usly generate two vertical planes eo
Press the H button to switch to the horizontal plane
Generate a horizontal plane
Long press the V button to adjust the laser line brightness (three scales).
Preface
T nk you for purchasing this brand new LM573R laser level. In order to use this product ha
safely and correctly, please r d this m al thoroughly, especially the Safety Instructions ea anu
part.
After reading this manual, it is recommended to k p the m ual at an ea ly accessible place, ee an si
preferably close to the device, for future reference.
Limited Warranty and Liability
Uni-Tr d guarantees that the proden uct is free from any defect in material and workmanship
within one year from the purchase date. This warranty es not apply to damages caused by do
acci nt, negligence, misuse, modification, contamination and impr er handling. The dealer de op
shall not be entitled to give any other warranty on behalf of Uni-Trend. If you need warranty
service within the warranty period, please contact your seller directly.
This warranty is the only compensation you can obtain. Uni-Trend will not be responsible for
any special, indirect, incidental or subsequent dam e or loss caused by any reason or ag
speculation. As some areas or countries do not allow limitations on implied warranties and
incidental or subsequent damage, the above limitation of liability and stipulation may not apply
to you.
P/N:110401112036X
